| T bolt clamp & T bolt clamp with spring | |||||
| T-bolt clamp | T-bolt clamp with spring | ||||
| SAE NO. | Size | SAE NO. | Size | ||
| Inch | mm | Inch | mm | ||
| 28 | 1 3/4-2 | 44-52 | / | / | / |
| 30 | 1 13/16-2 1/16 | 46-54 | / | / | / |
| 34 | 1 15/16-2 1/4 | 50-58 | / | / | / |
| 40 | 2 1/8-2 7/16 | 54-62 | 40 | 2 1/8-2 7/16 | 54-62 |
| 46 | 2 5/16-2 5/8 | 59-67 | 46 | 2 5/16-2 5/8 | 59-67 |
| 52 | 2 1/2-2 13/16 | 64-72 | 52 | 2 1/2-2 13/16 | 64-72 |
| 58 | 2 11/16-3 | 69-77 | 58 | 2 11/16-3 | 69-77 |
| 64 | 2 7/8-3 3/8 | 73-81 | 64 | 2 7/8-3 3/8 | 73-81 |
| 70 | 3 1/16-3 3/8 | 78-86 | 70 | 3 1/16-3 3/8 | 78-86 |
| 76 | 3 1/4-3 9/16 | 83-91 | 76 | 3 1/4-3 9/16 | 83-91 |
| 82 | 3 7/16-3 3/4 | 88-96 | 82 | 3 7/16-3 3/4 | 88-96 |
| 88 | 3 5/8-3 15/16 | 92-100 | 88 | 3 5/8-3 15/16 | 92-100 |
| 94 | 3 13/16-4 1/8 | 97-105 | 94 | 3 13/16-4 1/8 | 97-105 |
| 100 | 4-4 5/16 | 102-110 | 100 | 4-4 5/16 | 102-110 |
| 108 | 4 1/4-4 9/16 | 108-116 | 108 | 4 1/4-4 9/16 | 108-116 |
| 116 | 4 1/2-4 13/16 | 114-122 | 116 | 4 1/2-4 13/16 | 114-122 |
| 124 | 4 3/4-5 1/16 | 121-129 | 124 | 4 3/4-5 1/16 | 121-129 |
| 132 | 5-5 5/16 | 127-135 | 132 | 5-5 5/16 | 127-135 |
| 140 | 5 1/4-5 9/16 | 134-142 | 140 | 5 1/4-5 9/16 | 134-142 |
| 148 | 5 1/2-5 13/16 | 140-148 | 148 | 5 1/2-5 13/16 | 140-148 |
| 156 | 5 3/4-6 1/16 | 146-154 | 156 | 5 3/4-6 1/16 | 146-154 |
| 164 | 6-6 5/16 | 153-161 | 164 | 6-6 5/16 | 153-161 |
| 172 | 6 1/4-6 9/16 | 159-167 | 172 | 6 1/4-6 9/16 | 159-167 |
| 180 | 6 1/2-6 13/16 | 165-173 | 180 | 6 1/2-6 13/16 | 165-173 |
