Feature：

1. Low initial resistance, strong elasticity and wrinkle resistance

2. Stable structure, uniform air permeability, enabling uniform diffusion of airflow

3. High dust capture capability and long service life

4. The air outlet side of the ceiling filter is reinforced with high-performance fiber mesh or cloth to ensure strength and equal flow through the air.

5. 2 types with different glue spray treatment are available, there are surface glue and full glue for your option,

100% capture rate of dust particles large than 10μm by glue treatment

6. Silicone free

Application: Ceiling filter (Roof filter) is mainly used in the intake system and painting workshop of the spraying process with strict requirements for air purification.

1. Fine filtration of air supply system in paint room or spray booth.

2. Dust removal in Painting equipment, painting system and painting workshop.

3. Secondary filtering in high-quality painting system and air intake system of baking equipment.

4. As filter media for medium air panel filter.

5. Available to supply in cut pad or rolls, or as inner material for panel filter.

Technical Parameters
Main Material	Polyester fiber (PET)	Flammability Rating	F1(DIN53438) /  B1(GB/T 17591-2006)
Filtration Class	G4、M5 (EN779)	Dust Holding Capacity	500g/㎡, 550g/㎡, 600g/㎡, 650g/㎡
Filter Object	Coarse dust and foreign matter≥1μm	Temperature Resistance	≤100℃
Final Resistance	400Pa (Suggestion)	Instantaneous temp resistance	≤120℃
Average Weight Efficiency	98%(ASHRAE52.1-1992)	Humidity Resistance	≤100%RH

Specification
Model	Normal Size			Dust holding capacity	Rated air velocity	I.N.P	Initial air flow	Filtration Class
	L (m)	W (m)	T (mm)	g/㎡	m/s	Pa	m2/h	ISO 16890	EN779:2012
FRS-560G	14 / 21	1.6 / 2	22±2	500	0.3	≤45	1080	ePM10 60%	M5
FRS-600G	14 / 21	1.6 / 2	22±2	600	0.25	≤45	900	ePM10 60%	M5
FRS-600G/ZR	14 / 21	1.6 / 2	22±2	600	0.25	≤45	900	ePM10 60%	M5
Note: Other specifications are available on request.
