Product Description:
Ergonomic anti slip metal handle design.
The torque of the sensor testing is not related to the position of the user's grip on the handle, reducing human interference.
Torque accuracy: 1.5-340Nm forward ± 1% (20-100%), reverse ± 2% (20-100%). 500-2000Nm forward ± 2.5% (20-100%), reverse ± 3.5% (20-100%). Torque mode: Peak hold (P) and follow mode (T). Obvious reminder modes: Beep and light prompts, LED warning lights.
If the torque value is not within the tolerance range, a red reminder will be issued.
If the torque value is within the tolerance range, a green reminder will be issued.
Four torque units: N.m/in-b/ft-lb/kg-cm can be freely switched.
Power supply: Two No. 5 batteries, capable of continuous use for 110 hours, with a normal standby time of up to 1 year.
Power saving mode: 5 minutes without automatic shutdown.
Operating and storage temperature: can be used in the temperature range of -10 ℃ -60 ℃, storage temperature: -20 ℃ -70 ℃.
Humidity: Supports up to 90% non condensation.
Resolution: 30N. m (0.01N. m), above 500N. m (1N. m), other (0.1N. m)
1.5-340Nm with non removable quick release ratchet head (36 teeth) 500-2000Nm with non removable quick release ratchet head (48 teeth)
